#224: Shock Vibration Switch Module (KY-002)

R11.28

The KY-002 shock vibration switch module is a small electronic device that is used to detect shock or vibration. It consists of a metal ball that is suspended inside a tube by a spring, and an electrical contact that is connected to the ball. When the module is subjected to shock or vibration, the ball moves and makes contact with the electrical contact, completing a circuit and activating the module.

The KY-002 shock vibration switch module is typically used in applications where it is important to detect the presence of shock or vibration, such as in security systems, earthquake detectors, and industrial automation systems. It is a relatively simple and inexpensive device that is easy to use and install.

To use the KY-002 shock vibration switch module, it is typically connected to an electronic circuit, such as an Arduino microcontroller, using a set of wires. When the module is activated, it sends a signal to the circuit, which can then be used to trigger an action or alert. The specific details of how the module is used will depend on the specific application and the circuit it is connected to.

This switch is suitable for small current trigger circuit upon detecting shock/collisions. Perfect for Arduino.

• Omnidirectional, any angle can trigger
• This switch is suitable for small current trigger circuit
• Working voltage: 3.3V ~ 5V
• Digital switch output (0 & 1)
• Material: PCB
• Dimensions: 0.94 x 0.59 x 0.35inch (2.4 x 1.5 x 0.9cm)
• Component model: SW-18015P
