#12660: CNC 5-Axis PC Interface Breakout Board (Mach3)

R226.80

The CNC 5-Axis PC Interface Breakout Board is a specialized controller board designed for CNC (Computer Numerical Control) systems that use stepper motor drivers. It allows direct control of up to 5 single-axis 2-phase stepper motor driver controllers, such as M542, M542H, MA860H, 2M542, 2M982, DM542(A), DM860(A), and others. The board is compatible with CNC software like MACH3, Linux CNC (EMC2), and KCAM4 that support parallel port control.

The CNC 5-Axis PC Interface Breakout Board (Mach3) is a highly useful product for hobbyists, DIY enthusiasts, and professionals involved in CNC machining or automation projects. It offers several advantages and applications that make it a great tool to have in your CNC toolkit.

Advantages:

1. Versatility: The breakout board is designed to control up to 5 single-axis stepper motor drivers, providing flexibility for multi-axis CNC systems. This versatility allows users to handle complex CNC tasks, such as milling, engraving, and 3D printing, with precision and ease.

2. Compatibility: The board is compatible with popular CNC software like MACH3, Linux CNC (EMC2), and KCAM4. These software solutions offer powerful control capabilities and are widely used in the CNC community, making the board easily integratable into existing setups.

3. Opto-Isolated Signals: The opto-isolated input signals provide a significant advantage in terms of safety and protection. They prevent electrical interference from affecting the computer, reducing the risk of damage to the system and ensuring stable and reliable operation.

4. Built-In Protections: The board features protections against over-charge, over-discharge, and over-load situations. This ensures the safety of both the CNC system and the connected devices, preventing potential damage due to power fluctuations or short circuits.

Applications:

1. CNC Machines: The primary usage of the breakout board is to control CNC machines. Whether it's a DIY CNC router, a 3D printer, or a laser cutter, the board allows precise control of the stepper motor drivers, translating digital commands into accurate movements of the machine's axes.

2. Motor Speed Control: The board's output port with optocoupler isolation can be used to control the spindle speed of the CNC machine. This is essential for achieving different cutting speeds and tooling requirements.

3. Custom Bench Power Supply: The board can be used to recycle and convert an ATX computer power supply into a bench power supply, making it a versatile tool for electronics prototyping and testing.

4. Robotics and Automation: The breakout board can also be used in robotics and automation projects where stepper motors need to be precisely controlled to perform various tasks.

5. Educational Purposes: As a beginner-friendly breakout board, it is an excellent learning tool for those interested in understanding the principles of CNC control and stepper motor operation.

Overall, the CNC 5-Axis PC Interface Breakout Board provides an easy-to-use and efficient solution for controlling stepper motors and driving CNC machines. Its compatibility with popular CNC software, protection features, and flexibility in handling multiple stepper motor drivers make it a valuable asset for anyone working with CNC systems and automation projects.
